Novaris CB BNC RF Protectors are suited for RF signals at frequencies up to 3GHz.
Novaris CB BNC RF Protectors are suited for RF signals at frequencies up to 3GHz.
Application Notes Download
| Specifications | CD-MF-90-3 | CD-FF-90-3 | CD-MF-230-3 | CD-FF-230-3 | CD-MF-350-3 | CD-FF-350-3 | CD-MF-600-3 | CD-FF-600-3 | CD-MF-1000-3 | CD-FF-1000-3 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Spark-over voltage | U꜀ | 90V | 230V | 350V | 600V | 1000V | ||||||||||||||
| Maximum discharge current (8/20μs) | Iₘₐₓ | 20kA | ||||||||||||||||||
| Maximum impulse current (10/350μs) | Iᵢₘₚ | 5kA | ||||||||||||||||||
| Impulse durability | C2 8/20μs 5kA | |||||||||||||||||||
| Power rating | 25W | 150W | 350W | 1000W | 2500W | |||||||||||||||
| Voltage protection level @ 1kV/μs | Uₚ | 650V | 820V | 1.1kV | 1.3kV | 1.8kV | ||||||||||||||
| VSWR | < 1.1 : 1 | |||||||||||||||||||
| Connector orientation | M / F | F / F | M / F | F / F | M / F | F / F | M / F | F / F | M / F | F / F | ||||||||||
| Dimensions | 📐 | W 80mm x H 40mm x D 40mm | ||||||||||||||||||
| Weight | 📦 | 300g | ||||||||||||||||||
| Product Datasheet | CD-MF-90-3 | CD-FF-90-3 | CD-MF-230-3 | CD-FF-230-3 | CD-MF-350-3 | CD-FF-350-3 | CD-MF-600-3 | CD-FF-600-3 | CD-MF-1000-3 | CD-FF-1000-3 | ||||||||||
